Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic

Name: Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic
Brand: Shenzhen Duoyi Technology CO., Ltd.
Price: 4.0 USD
Availability: InStock

Price 4.0 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic Specification

Soldermask
Yes

Flame Resistance Level
UL94V-0

Silkscreen
White

Voltage Endurance
5V

Insulation Resistance
High

Test
Function Tested

Board Type
IC Chip

Product Type
Microcontroller IC

Base Material
Silicon

Surface Finish
Standard

Copper Thickness
Standard

Board Thickness
Standard

Color
Black

Panel Size
SOP-10

Sensor Switch
No

Electrical Components
Integrated Circuit

Model Number
HX66 ESSOP-10

Application
USB Card Reader, OTG Card Reader, PC Peripherals

Supported Card Types
MicroSD (TF), SD Card

ESD Protection
Built-in

Operating Temperature
-40C to 85C

Power Supply
3.3V/5V

Interface
USB 2.0

Data Transfer Rate
Up to 480 Mbps (High-Speed USB 2.0)

Mounting Type
Surface Mount

RoHS Compliant
Yes

Compatibility
Support for Windows, Mac, Android, Linux

Package Type
ESSOP-10

Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Shenzhen

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
50000000000 Pieces Per Month

Delivery Time
1 Week

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
4000 pcs per package

Main Export Market(s)
Asia, Australia, Central America, Middle East, Africa, North America, South America, Eastern Europe, Western Europe

Main Domestic Market
All India

Certifications
ROHS

About Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic

Briefly describe

Compliant with USB 2.0 specification standards

Compliant with 480Mbps Universal Serial Bus specification version 2.0 and backward compatible with version 1.0

1.0 supports one device address and up to four endpoints:

Control (0)/BulkRead (1)/BulkWrite (2)/Interrupt (3)

Integrated USB building block USB 2.0 transceiver (UTM), serial interface engine (SIE),

Built in power on reset (POR) and low voltage detector (LVD)

Standardize v3x/v4.0/v4.1/v4.2- Supports 1/4 bit data bus and SD3.0

Upgrade mode for better performance support Non SD card detection pin MS insertion/deletion pin design to save BOM costs Support non SD write protection pin design to save BOM costs,

No need for a 12 MHz crystal clock

Input chip 5V to 3.3V and 3.3V to 1.8V voltage regulators

High-Speed Performance and Versatility

Engineered for efficiency, the HX66 ESSOP-10 controller IC employs USB 2.0 interface standards, allowing fast data exchanges with speeds up to 480 Mbps. Its broad OS compatibility and dual-voltage support (3.3V/5V) make it a steadfast option for a variety of USB card reader projects, ensuring seamless integration across multiple platforms.

Reliable and Robust Design

This IC chip is built to withstand rigorous environments thanks to wide operating temperature ranges (-40C to 85C), high insulation resistance, and flame resistance rated at UL94V-0. Its black, silicon-based construction and surface-mount design maximize reliability, making it ideal for demanding electronic applications.

FAQ's of Hx66 Essop-10 Usb 2.0 Card Reader Controller Ic Usb Card Reader Solution Ic Chip Sd Card Tf Card Reader Ic:

Q: How do I integrate the HX66 ESSOP-10 IC into a USB card reader design?

A: Simply solder the surface mount package onto your PCB, ensuring proper power connections (3.3V/5V) and aligning the USB 2.0 interface pins with your circuit. The IC is function-tested and ready for integration with brief setup for SD or TF card slots.

Q: What card types does this controller IC support?

A: The HX66 ESSOP-10 is compatible with both SD cards and MicroSD (TF) cards, making it versatile for various memory card reader applications.

Q: When should I choose this IC for my design?

A: This IC is ideal when you require reliable, high-speed data transfer in card readers operating in environments from -40C to 85C, and need compatibility across popular operating systems like Windows, Mac, Android, and Linux.

Q: Where is the HX66 ESSOP-10 manufactured and supplied from?

A: The HX66 ESSOP-10 is manufactured in China and available through distributors, exporters, manufacturers, suppliers, and traders.

Q: What are the process and safety benefits of this card reader solution?

A: Benefits include built-in ESD protection for safety, RoHS compliance for environmental standards, high insulation resistance, flame resistance (UL94V-0), and standard, tested surface finishes ensuring a reliable and safe electronic component.

Q: How does ESD protection enhance the durability of the IC?

A: Built-in ESD (electrostatic discharge) protection safeguards the IC against voltage surges and static electricity, prolonging device life and reliability during handling and operation.
