SL6341 USB3.2 GeniX1 interface 4-port hub controller integrated circuit

Name: SL6341 USB3.2 GeniX1 interface 4-port hub controller integrated circuit
Brand: Shenzhen Duoyi Technology CO., Ltd.
Price: 1.0 USD
Availability: InStock

Price 1.0 USD ($)/ Piece

Get a Price/Quote

MOQ : 4000 Pieces

SL6341 USB3.2 GeniX1 interface 4-port hub controller integrated circuit Specification

Components
CMOS, ESD protection, X1 crystal oscillator support

Operating Temperature
-40C to +85C

Interface
USB 3.2 Gen1 (Backward compatible with USB 2.0/1.1)

Input
1 x USB 3.2 Gen1 upstream port

Usage
Expansion of USB ports

Charging Voltage
5V (per downstream port)

Power Source
USB BUS or external adapter

Response Time
Low-latency USB signal routing

Power Supply
Bus-powered or self-powered

Output
4 x USB 3.2 Gen1 downstream ports

Features
Plug and play, supports USB battery charging (BC1.2), over-current protection, hot plug support

Thermal Conductivity
Standard IC package

Product Type
Integrated Circuit (IC) - USB Hub Controller

Application
Motherboards, laptops, docking stations, USB hubs

Rated Voltage
5V DC

Supply Voltage
3.3V core, 5V I/O

Size
9 mm x 9 mm (package)

Dimension (L*W*H)
9 mm x 9 mm x 0.85 mm

Function
USB 3.2 Gen1 4-port hub controller

Color
Black (as per package image)

Weight
Approx. 2g (typical for IC)

Current Rating
Up to 1.5A per port (power switching dependent)

Thickness
0.85 mm (package thickness)

Capacity
Supports 4 downstream ports

Frequency
Up to 5 Gbps (SuperSpeed)

Compliance
USB-IF certified, RoHS compliant

Max Data Rate
5 Gbps per port

Hot Plug Capability
Supported

Downstream Port Power Management
Individual port power switching and over-current protection

Mounting Type
SMT (Surface Mount Technology)

Crystal Oscillator Support
12 MHz, external

Integrated Transceivers
High-speed and SuperSpeed PHYs included

ESD Protection
>8kV human-body model

Firmware Upgrade Capability
Supports external firmware upgrade via vendor mode

Reference Design Availability
Yes, standard USB hub reference design

Power Consumption
Low power, typ. <250 mW

Package Type
QFN-48

Backward Compatibility
Supports USB 2.0 and USB 1.1 devices

SL6341 USB3.2 GeniX1 interface 4-port hub controller integrated circuit Trade Information

Minimum Order Quantity
4000 Pieces

FOB Port
Shenzhen

Payment Terms
Telegraphic Transfer (T/T)

Supply Ability
200000 Pieces Per Month

Delivery Time
1 Week

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
4000 pcs per package

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ROHS

About SL6341 USB3.2 GeniX1 interface 4-port hub controller integrated circuit

SL6340 is a 4-port HUB controller chip with USB 3.2 GeniX1 interface, integrated with 32 chips on-chip

Bit microprocessor, which has the characteristics of low power consumption, high performance, and configurable; Chip integrated USB 3.0 high-speed device

The layer transceiver and USB2.0 high-speed physical layer transceiver enable the chip to perfectly support ultra high speed and high speed

Connect to low-speed USB upstream and downstream devices; High chip integration, internal integration of 5V to 3.3V and 5V to 1.1V

DCDC Greatly streamlined peripheral circuits.

SL6340 supports BC1.2 fast charging protocol that complies with USB IF specifications, and it can be used for Apple and Samsung devices

Provide a maximum charging current of 1.5A.

SL6340 supports configuring device information through external SPI flash/EEPROM. This version of SL6340 chip

SPI-FLASH must be configured for use, and our company provides a configuration program/or a SPI-FLASH that completes program configuration.
